TECHNICAL DATA:

-Pump

Max.immersion depth: 5 m

Max.liquid temperature: +40 ℃

Liquid pH value: 4-10

Liquid kinematic viscosity: 7×10-7~23×10-6m2/s

Max.liquid density: 1.2×103kg/m3


-Motor

Copper winding

Built-in thermal protector

Stainless steel welded shaft

Insulation class: B

Protection class: IP68


MODEL POWER AMPERE OUTLET
(inch)
VOLTAGE
(V/HZ)
MAX. FLOW
(L/MIN)
MAX. HEAD
(M)
G. W.
(Kg)
DIMENSIONS.
(mm)
KW HP
V1100S-F 1.1 1.5 6 2" 220/50 360 12 22.5 530×220×260
V1500S-F 1.5 2 6.5 2" 220/50 400 14 25.5 550×220×260




MODEL POWER AMPERE QUTLET
(inch)
VOLTAGE
(V/HZ)
MAX.FLOW
(L/MIN)
MAX.HEAD
(M)
G.W.
(Kg)
DIMENSIONS.
(mm)
Kw Hp
V1100S-F 1.1 1.5 5 2″ 220/50 360 12 22.5 530×220×260
V1500S-F 1.5 2 7 2″ 220/50 440 14 25.5 550×220×260
V2200S-F 2.2 3 8 2″ 220/50 470 15 27 570×220×260
