4DSP-A/D(6/8)

rpm:4000

Model	(AC) Voltage (V)	(DC) Voltage (V)	Motor power		Max Flow (M³/H)	Max Head (M)	Outlet (IN)	Cable (m)	Solar Panels Suggestion(≥1.3*PUMP POWER)
			Motor power						Open circuit voltage (VOC)(V)	Quantity(pcs)
			KW	HP					Open circuit voltage (VOC)(V)	Quantity(pcs)
4DSP6-87-A220/D110-750	85-280V	80-430V	0.75	1	6	87	1.25"	2m	<430V	3
4DSP6-102-A220/D150-1100	85-280V	80-430V	1.1	1.5	6	102	1.25"	2m	<430V	4
4DSP6-135-A220/D200-1500	85-280V	80-430V	1.5	2	6	135	1.25"	2m	<430V	5
4DSP6-190-A220/D300-2200	85-280V	80-430V	2.2	3	6	190	1.25"	2m	<430V	7
4DSP6-190-A380/D550-2200	323-540V	200-780V	2.2	3	6	190	1.25"	2m	<780V	8
4DSP6-262-A380/D550-3000	323-540V	200-780V	3.0	4	6	262	1.25"	2m	<780V	8
4DSP6-300-A380/D550-4000	323-540V	200-780V	4.0	5.5	6	300	1.25"	2m	<780V	10
4DSP6-350-A380/D550-5500	323-540V	200-780V	5.5	7.5	6	350	1.25"	2m	<780V	13
4DSP6-490-A380/D550-7500	323-540V	200-780V	7.5	10	6	490	1.25"	2m	<780V	18
4DSP8-56-A220/D110-750	85-280V	80-430V	0.75	1	8	56	1.5°	2m	<430V	3
4DSP8-100-A220/D150-1100	85-280V	80-430V	1.1	1.5	8	100	1.5°	2m	<430V	4
4DSP8-121-A220/D200-1500	85-280V	80-430V	1.5	2	8	121	1.5"	2m	<430V	5
4DSP8-180-A220/D300-2200	85-280V	80-430V	2.2	3	8	180	1.5"	2m	<430V	7
4DSP8-180-A380/D550-2200	323-540V	200-780V	2.2	3	8	180	1.5°	2m	<780V	8
4DSP8-248-A380/D550-3000	323-540V	200-780V	3.0	4	8	248	1.5"	2m	<780V	8
4DSP8-280-A380/D550-4000	323-540V	200-780V	4.0	5.5	8	280	1.5"	2m	<780V	10
4DSP8-340-A380/D550-5500	323-540V	200-780V	5.5	7.5	8	340	1.5"	2m	<780V	13
4DSP8-476-A380/D550-7500	323-540V	200-780V	7.5	10	8	476	1.5"	2m	<780V	18
