4DSP-A/D(10/13)

rpm:4000

Model	(AC) Voltage (V)	(DC) Voltage (V)	Motor power		Max Flow (M³/H)	Max Head (M)	Outlet (IN)	Cable (m)	Solar Panels Suggestion(≥1.3*PUMP POWER)
			Motor power						Open circuit voltage (VOC)(V)	Quantity(pcs)
			KW	HP					Open circuit voltage (VOC)(V)	Quantity(pcs)
4DSP10-60-A220/D110-750	85-280V	80-430V	0.75	1	10	60	2"	2m	<430V	3
4DSP10-75-A220/D150-1100	85-280V	80-430V	1.1	1.5	10	75	2"	2m	<430V	4
4DSP10-98-A220/D200-1500	85-280V	80-430V	1.5	2	10	98	2"	2m	<430V	5
4DSP10-140-A220/D300-2200	85-280V	80-430V	2.2	3	10	140	2"	2m	<430V	7
4DSP10-140-A380/D550-2200	280-450V	200-780V	2.2	3	10	140	2"	2m	<780V	8
4DSP10-200-A380/D550-3000	280-450V	200-780V	3.0	4	10	200	2"	2m	<780V	8
4DSP10-255-A380/D550-4000	280-450V	200-780V	4.0	5.5	10	255	2"	2m	<780V	10
4DSP10-320-A380/D550-5500	280-450V	200-780V	5.5	7.5	10	320	2"	2m	<780V	13
4DSP10-460-A380/D550-7500	280-450V	200-780V	7.5	10	10	460	2"	2m	<780V	18
4DSP13-50-A220/D110-750	85-280V	80-430V	0.75	1	13	50	2"	2m	<430V	3
4DSP13-63-A220/D150-1100	85-280V	80-430V	1.1	1.5	13	63	2"	2m	<430V	4
4DSP13-95-A220/D200-1500	85-280V	80-430V	1.5	2	13	95	2"	2m	<430V	5
4DSP13-127-A220/D300-2200	85-280V	80-430V	2.2	3	13	127	2"	2m	<430V
4DSP13-127-A380/D550-2200	323-540V	200-780V	2.2	3	13	127	2"	2m	<780V
4DSP13-168-A380/D550-3000	323-540V	200-780V	3.0	4	13	168	2"	2m	<780V
4DSP13-196-A380/D550-4000	323-540V	200-780V	4.0	5.5	13	196	2"	2m	<780V
4DSP13-270-A380/D550-5500	323-540V	200-780V	5.5	7.5	13	270	2"	2m	<780V
4DSP13-350-A380/D550-7500	323-540V	200-780V	7.5	10	13	350	2"	2m	<780V
