3DSP(6/7/10)

rpm:4000

Model	(DC) Voltage (V)	Best input voltage(DC) (V)	Motor power		Max Flow (M³/H)	Max Head (M)	Outlet (IN)	Cable (m)	Solar Panels Suggestion(≥1.3*PUMP POWER)
			Motor power						Open circuit voltage(VOC)(V)	Quantity(pcs)
			KW	HP					Open circuit voltage(VOC)(V)	Quantity(pcs)
3DSP6/50-D48/600	48V	40-110V	0.6	0.82	6	50	1.5"	2m	<110V	2
3DSP6/67-D72/750	72V	60-165V	0.75	1	6	67	1.5"	2m	<165V	3
3DSP6/92-D72/1100	72V	60-165V	1.1	1.5	6	92	1.5"	2m	<165V	3
3DSP6/92-D110/1100	110V	80-220V	1.1	1.5	6	92	1.5°	2m	<220V	4
3DSP6/128-D110/1500	110V	80-220V	1.5	2	6	128	1.5"	2m	<220V	4
3DSP7/39-D48/600	48V	40-110V	0.6	0.82	7	39	1.5"	2m	<110V	2
3DSP7/45-D72/750	72V	60-165V	0.75	1	7	45	1.5"	2m	<165V	3
3DSP7/70-D72/1100	72V	60-165V	1.1	1.5	7	70	1.5°	2m	<165V	3
3DSP7/70-D110/1100	110V	80-220V	1.1	1.5	7	70	1.5"	2m	<220V	4
3DSP7/85-D110/1500	110V	80-220V	1.5	2	7	85	1.5°	2m	<220V	4
3DSP10/30-D48/600	48V	40-110V	0.6	0.82	10	30	1.5°	2m	<110V	2
3DSP10/37-D72/750	72V	60-165V	0.75	1	10	37	1.5"	2m	<165V	3
3DSP10/52-D72/1100	72V	60-165V	1.1	1.5	10	52	1.5"	2m	<165V	3
3DSP10/52-D110/1100	110V	80-220V	1.1	1.5	10	52	1.5"	2m	<220V	4
3DSP10/66-D110/1500	110V	80-220V	1.5	2	10	66	1.5"	2m	<220V	4
