ST

rpm:3600

Model	(AC) Voltage (V)	(DC) Voltage (V)	Motor power		Max Flow (M³/H)	Max Head (M)	Size (DN)	Solar Panels Suggestion(≥1.3*PUMP POWER)
			Motor power					Open circuit voltage(VOC)(V)	Quantity(pcs)
			KW	HP				Open circuit voltage(VOC)(V)	Quantity(pcs)
ST27-44-3	323-540V	200-780V	3	4	27	44.2	50*32	<780V	8
ST27-55-4	323-540V	200-780V	4	5.5	27	54.5	50*32	<780V	10
ST24-53-5.5	323-540V	200-780V	5.5	7.5	24	53	50*32	<780V	13
ST24-61-7.5	323-540V	200-780V	7.5	10	24	61	50*32	<780V	18
ST24-75-9.2	323-540V	200-780V	9.2	12.5	24	75	50*32	<780V	22
ST24-90-11	323-540V	200-780V	11	15	24	90	50*32	<780V	26
ST24-97-15	323-540V	200-780V	15	20	24	91	50*32	<780V	36
ST42-32-3	323-540V	200-780V	3	4	42	31.8	50*32	<780V	8
ST48-38-4	323-540V	200-780V	4	5.5	48	38	50*32	<780V	10
ST42-46-5.5	323-540V	200-780V	5.5	7.5	42	46	50*32	<780V	13
ST48-57-7.5	323-540V	200-780V	7.5	10	48	57	50*32	<780V	18
ST48-64-9.2	323-540V	200-780V	9.2	12.5	48	64	50*32	<780V	22
ST48-72-11	323-540V	200-780V	11	15	48	72	50*32	<780V	26
ST48-85-15	323-540V	200-780V	15	20	48	84.5	50*32	<780V	36
ST48-90-18.5	323-540V	200-780V	18.5	25	48	90	50*32	<780V	45
ST72-20-3	323-540V	200-780V	3	4	72	20	65*50	<780V	8
ST84-28-4	323-540V	200-780V	4	5.5	84	28	65*50	<780V	10
ST84-32-5.5	323-540V	200-780V	5.5	7.5	84	32	65*50	<780V	13
ST90-40-7.5	323-540V	200-780V	7.5	10	90	40	65*50	<780V	18
ST84-51-9.2	323-540V	200-780V	9.2	12.5	84	50.5	65*50	<780V	22
ST90-58-11	323-540V	200-780V	11	15	90	57.5	65*50	<780V	26
ST90-62-15	323-540V	200-780V	15	20	90	62	65*50	<780V	36
ST84-69-15	323-540V	200-780V	15	20	84	69	65*50	<780V	36
ST90-79-18.5	323-540V	200-780V	18.5	25	90	79	65*50	<780V	45
ST90-90-22	323-540V	200-780V	22	30	90	89.5	65*50	<780V	56
ST90-19-4	323-540V	200-780V	4	5.5	90	19	80*65	<780V	10
ST108-23-5.5	323-540V	200-780V	5.5	7.5	108	23	80*65	<780V	13
ST120-27-7.5	323-540V	200-780V	7.5	10	120	27	80*65	<780V	18
ST120-33-9.2	323-540V	200-780V	9.2	12.5	120	33	80*65	<780V	22
ST120-36-11	323-540V	200-780V	11	15	120	36	80*65	<780V	26
ST138-42-15	323-540V	200-780V	15	20	138	42	80*65	<780V	36
ST120-45-15	323-540V	200-780V	15	20	120	45	80*65	<780V	36
ST120-52-18.5	323-540V	200-780V	18.5	25	120	52	80*65	<780V	45
ST138-59-22	323-540V	200-780V	22	30	138	59	80*65	<780V	56
ST120-17-4	323-540V	200-780V	4	5.5	120	17	100*80	<780V	10
ST138-21-5.5	323-540V	200-780V	5.5	7.5	138	21	100*80	<780V	13
ST138-26-7.5	323-540V	200-780V	7.5	10	138	26	100*80	<780V	18
ST180-28-11	323-540V	200-780V	11	15	180	28	100*80	<780V	26
ST210-34-15	323-540V	200-780V	15	20	210	34	100*80	<780V	36
ST210-39-18.5	323-540V	200-780V	18.5	25	210	39	100*80	<780V	45
ST210-44-22	323-540V	200-780V	22	30	210	44	100*80	<780V	56
ST240-35-15	323-540V	200-780V	15	20	240	35	125*100	<780V	36
ST240-39-18.5	323-540V	200-780V	18.5	25	240	38.5	125*100	<780V	45
ST240-43-22	323-540V	200-780V	22	30	240	43	125*100	<780V	56
